Customized PCB Mount Pogo Pins

Double Head Spring Loaded PCB Pins

Spring Loaded PCB Pins 3A

Product Description

Customized 3A Double Head Spring Loaded Pogo Pin For PCB Board

Customized double head pogo pin for PCB board,UPE is a professional manufacturer of pogo pin and pogo pin connector and provide professional POGO PIN customization service.

UPE Pogo Pin Internal Structure according to customer requirements to match suitable one

Customized PCB Mount Pogo Pins Double Head Spring Loaded PCB Pins 3A For PCB Board 0

UPE Pogo Pin External Structure:

Customized PCB Mount Pogo Pins Double Head Spring Loaded PCB Pins 3A For PCB Board 1

Spring-Loaded Pogo Pin parameter performance:

Name of Parts	Parameter performance table
Barrel Materia	Brass	Beryllium copper	Phosphor Bronze
Plunger Material	Brass	Beryllium copper	Phosphor Bronze	Stainless steel
Spring options	Stainle	Music wire
Plating requirements	Gold-Au	Silver-Ag	Palladium-Nickel (Pd-Ni)
Rated Current	1A, 2A, 3A ,5A,15A or 30A (different structures)
Rated Voltage	DC 12V 24V
Contact Resistance	30mΩ 50mΩ Max. (stillness)
Life test	50,000 cycles Min. 1000,000 cycles Max
Reflow Temp.	265°, 4~5sec
POGO PIN Reliability Test
Retention Force	At rated cycling of 500±50 per hour,50,000 cycles minimum
Humidity	EIA-364-31,Test method II, Condition A Subject mated connectors to relative humidity of 90% to 95%RH and a temperature of 40℃ ± 2℃ relative humidity for 96 hour.
Resistance to Solder Heat	EIA-364-56,Procedure 5,Level 2 265℃+10/-0℃for 30 to 35 seconds
Salt Spray	EIA-364-26,Test condition B Subject mated connectors to 5±1% salt-solution concentration, 35+1℃/-2℃ for 48 hours.
Spring force test	Normal Force Test Procedure,100g±20g at working height
Temperature Life	EIA-364-17,Test method A,condition 4,Test time condition A Subject mated connectors to 85℃± 2℃ for 96 hours.
Solderability	EIA-364-52 Dip into the 265±5℃, 60/40±5% Sn/pb solder for 4.0~5.0 second
Contact Resistance	EIA-364-23 Measure the contact resistance with a test current of 100 mA maximum and 20 mV voltage maximum

Product Application:
1)PCB board;
2)Digital camera/Medical products/ Printer cartridges;
3)Golf handle/ Electric vehicles/ Telephony applications;
4)Cardiac defibrillator/Car charging /Air purifier;
5)LED flat luminaries/LED flash light/Tablet/Laptop/PC ;
6)Power bank/ Digital product/ Small household electrical application;
7)Charging products/Signal transmission products etc

Why do customers choose UPE?
1. Pogo Pin professional customization service
Different products and solutions can be designed according to different customer needs

2. Fast sample production capability
Standard product 2-3 days sample, new custom sample 7 working days, mold opening product 12 days

3. Strict quality control system
The concept of quality first runs through the entire production and inspection process, and strictly controls each process to ensure the quality of customer satisfaction.

4. Processing with imported components
A small number of needle shafts are machined from imported precision lathes, and most of the needle shafts are made of imported cold stamping for higher stability.

5. High-precision test equipment
Provide accurate and precise testing to continuously improve product quality

6. Reasonable cost control procedures
Save costs, eliminate waste, optimize processes, and highlight cost competitiveness

7. Product environmental standards
The product meets the EU ROHS standard and meets halogen

Quality management process:
From material purchasing management, to open mold trail sample, and then to the whole process of production,layer by control inspection, full quality control, to ensure what the supply of products to meet customer needs, to achieve the product qualified rate of more than 98%.

Tag:

Place of Origin:	China
Brand Name:	UPE
Certification:	ISO9001

Minimum Order Quantity:	10000
Price:	$0.1-$0.5
Packaging Details:	PE
Delivery Time:	10-12 working days
Payment Terms:	T/T
Supply Ability:	50KPCS/Day

Customized PCB Mount Pogo Pins Double Head Spring Loaded PCB Pins 3A For PCB Board
